连连支付对接工具：java-sdk 使用文档
一、简介
适用于 JAVA 6 及以上的开发环境。
二、使用说明
概述：连连支付将与服务端交互的接口（OpenAPI）封装在开发工具包（SDK）中，开发者无需自行实现同服务端交互的复杂逻辑，直接将 SDK jar 包引入自己的工程后，通过 OpenAPI 的示例代码实现同连连支付服务端的交互
适用人群
本文阅读对象：商户系统集成连连支付涉及的技术架构师，研发工程师，测试工程师，系统运维工程师等相关人员
三、支持接口
提供创单支付、退款、支付查询、退款查询、物流上传、支付取消、获取 iframe 支付 token 方法、支付/退款通知接口，开发者只需修改部分参数即可调用
目前已支持的接口，如 api 文档所示 ：https://doc.lianlianpay.com/doc-api/open-api/pay-order
四、开发准备
相关依赖
sdk jar 包资源：
globalpay-sdk-0.0.5.zip
sdk 使用 demo 资源：
pay-v3-sdk-demo-java.zip
所需额外依赖资源：https://mvnrepository.com/artifact/org.apache.httpcomponents/httpclient/4.5.2
引入 sdk：
方式一：将 sdk jar 包上传至贵公司 maven 仓库
1.上传至maven仓库
mvn deploy:deploy-file -DgroupId=com.lianpay.globalpay -DartifactId=globalpay-sdk -Dversion=0.0.5 -Dpacckaging=jar -Dfile=globalpay-sdk-0.0.5.jar -DrepositoryId=maven-releases -Durl=maven url
–Dversion 版本信息
-DrepositoryId 仓库标识id
-Durl 私服上仓库的位置，打开nexus——>repositories菜单，可以看到该路径。
-Dfile 直接写文件名即可
2.使用依赖
maven:
<dependency>
<groupId>com.lianpay.globalpay</groupId>
<artifactId>globalpay-sdk</artifactId>
<version>0.0.5</version>
</dependency>
<dependency>
<groupId>org.apache.httpcomponents</groupId>
<artifactId>httpclient</artifactId>
<version>4.5.2</version>
</dependency>
gralde:
compile group: ‘com.lianpay.globalpay’, name:’globalpay-sdk’, version:’0.0.5′
complie group: ‘org.apache.httpcomponents’, name:’httpclient’, version:’4.5.2′
方式二：使用本地 sdk jar 包方式
1.maven
<dependency>
<groupId>com.lianpay.globalpay</groupId>
<artifactId>globalpay-sdk</artifactId>
<version>0.0.5</version>
<type>jar</type>
<scope>system</scope>
<systemPath>${basedir}/lib/globalpay-sdk-0.0.5.jar</systemPath>
</dependency>
<dependency>
<groupId>org.apache.httpcomponents</groupId>
<artifactId>httpclient</artifactId>
<version>4.5.2</version>
</dependency>
2.gradle
dependencies { compile files(‘lib/globalpay-sdk-0.0.5.jar’)}
complie group: ‘org.apache.httpcomponents’, name:’httpclient’, version:’4.5.2′
修改商户参数
商户配置文件信息修改：商户号、连连公钥、商户私钥、环境设置
#可参考pay-v3-sdk-demo-java.zip中globalpay-merchant.properties
# ON / OFF
DEBUGGER_FLAG=ON
# (测试模式)ON / OFF
TEST_MODEL=ON
# 商户号 连连提供
MERCHANT_ID=
# 二级商户号 连连提供(若无则不填)
SUB_MERCHANT_ID=
# 见 AlgorithmEnum
SIGN_TYPE=RSA
# 配置商户秘钥
# RSA – 商户私钥 – 商户自己创建
# HMAC – 连连提供的HMAC key
MERCHANT_SIGN_KEY=
# 配置连连秘钥
# RSA – 连连公钥 – 连连提供
# HMAC – 连连提供的HMAC key
LL_SIGN_KEY=
五、SDK 调用示例代码
LianLianpay SDK 集成说明:SDK 已经对加签验签逻辑做了封装，使用 SDK 时传入商户公钥等内容可直接通过 SDK 自动进行加验签，签名方法：加签验签详情参见https://doc.lianlianpay.com/pay-guide/dev-ready/rule
创单支付调用示例
public class PaymentsTest {
private final MerchantPropertyReader merchant = new MerchantPropertyReader(“/globalpay-merchant.properties”);
private final PaymentsService payService = new PaymentsService();
public void testPaySuccess() {
//创单支付接口详细请见: https://doc.lianlianpay.com/doc-api/open-api/pay-order
PaymentsRequest payRequest = buildCheckoutPagePayRequest();
ApiResult<PaymentsResponse> s = payService.sendPaymentRequest(payRequest, merchant);
}
}
备注：CheckoutPage 模式见代码 demo 包中 CheckoutPagePaymentsTest 测试类,IFrame 模式见 IFramePaymentsTest 测试类,Direct Api 模式见 DirectApiPaymentsTest 测试类。
退款调用示例
public class RefundTest {
private final MerchantPropertyReader merchant = new MerchantPropertyReader(“/globalpay-merchant.properties”);
private final RefundService refundService = new RefundService();
public void testRefund() {
//退款接口详细请见：https://doc.lianlianpay.com/doc-api/open-api/pay-result
RefundRequest request = buildRefundRequest();
//原始交易订单号 必填
request.setOriginalTransactionId(“”);
ApiResult<RefundResponse> refundResponseApiResult = refundService.sendRefundRequest(request, merchant);
}
}
支付结果查询调用示例
public class PaymentsQueryTest {
private final MerchantPropertyReader merchant = new MerchantPropertyReader(“/globalpay-merchant.properties”);
private final PaymentsQueryService paymentsQueryService = new PaymentsQueryService();
public void testPaymentsQuery() {
//支付查询接口详细请见：https://doc.lianlianpay.com/doc-api/open-api/pay-result
String merchantTransactionId = “”;
ApiResult<PaymentsResponse> payResponseApiResult = paymentsQueryService.sendPaymentQueryRequest(merchantTransactionId, merchant);
}
}
退款结果查询调用示例
public class RefundQueryTest {
private final MerchantPropertyReader merchant = new MerchantPropertyReader(“/globalpay-merchant.properties”);
private final RefundQueryService refundQueryService = new RefundQueryService();
public void testRefundQuery() {
//退款查询接口详细请见：https://doc.lianlianpay.com/doc-api/open-api/refund-result
String merchantTransactionId = “”;
ApiResult<RefundResponse> refundResponseApiResult = refundQueryService.sendRefundQueryRequest(merchantTransactionId, merchant);
}
}
支付取消调用示例
public class PaymentsCancelTest {
private final MerchantPropertyReader merchant = new MerchantPropertyReader(“/globalpay-merchant.properties”);
private final PaymentsCancelService paymentsCancelService = new PaymentsCancelService();
public void testPaymentsCancel() {
//支付取消接口详细请见：https://doc.lianlianpay.com/doc-api/open-api/pay-cancel
String merchantTransactionId = “”;
ApiResult<CancelPayResponse> cancelPayResponseApiResult = paymentsCancelService.sendPaymentCancelRequest(merchantTransactionId, merchant);
}
}
物流上传调用示例
public class ShipmentsUploadTest {
private final MerchantPropertyReader merchant = new MerchantPropertyReader(“/globalpay-merchant.properties”);
private final ShipmentsService shipmentsService = new ShipmentsService();
public void testShipmentsUpload() {
//物流上传接口详细请见：https://doc.lianlianpay.com/doc-api/open-api/logistics
ShipmentRequest shipmentRequest = buildShipmentRequest();
ApiResult<?> apiResult = shipmentsService.sendShipmentsRequest(shipmentRequest, merchant);
}
}
获取 iframe 支付 token 调用示例
public class IFrameToken {
private final MerchantPropertyReader merchant = new MerchantPropertyReader(“/globalpay-merchant.properties”);
private final IFrameTokenService iFrameTokenService = new IFrameTokenService();
public void testGetIframeToken() {
//获取IFrame支付token详情见：https://doc.lianlianpay.com/doc-api/open-api/get-token
ApiResult<String> iFrameTokenRes = iFrameTokenService.sendIFrameTokenRequest(merchant);
}
}
支付结果通知调用示例
public class PaymentsNotifyTest {
private final MerchantPropertyReader merchant = new MerchantPropertyReader(“/globalpay-merchant.properties”);
private final PaymentNotifyService paymentNotifyService = new PaymentNotifyService();
public void testPaymentNotify() {
System.out.println(“支付通知详细请见：https://doc.lianlianpay.com/doc-api/open-news/pay-result”);
//通知头部信息
Map<String, String> headers;
//通知body体信息
String requestBody;
PaymentsNotifyRequest paymentsNotifyRequest = paymentNotifyService.checkNotifySignAndGetPaymentsNotifyRequest(headers, requestBody, merchant);
}
}
退款结果通知调用示例
public class RefundNotifyTest {
private final MerchantPropertyReader merchant = new MerchantPropertyReader(“/globalpay-merchant.properties”);
private final RefundNotifyService refundNotifyService = new RefundNotifyService();
public void testRefundNotify() {
System.out.println(“退款通知详细请见：https://doc.lianlianpay.com/doc-api/open-news/refund-result”);
//通知头部信息
Map<String, String> headers;
//通知body体信息
String requestBody;
RefundNotifyRequest refundNotifyRequest = refundNotifyService.checkNotifySignAndGetRefundNotifyRequest(headers, requestBody, merchant);
}
}
生成公私钥示例
public class RsaPairKeyTest {
public static void main(String[] args) throws Exception {
ImmutablePair<String, String> rsaKeyPair = SignUtil.initRsaKey();
System.out.println(“获取Rsa公钥：” + rsaKeyPair.getLeft());
System.out.println(“获取Rsa私钥：” + rsaKeyPair.getRight());
}
}
